MODEL NUMBER
SCM-PD4CH
DESCRIPTION
The SHADOW-CASTER® SCM-PD4CH is a 4-position power distribution box that provides a convenient way to connect up to 4 SHADOW-CASTER® underwater lights. Digital over-current protection for each output insures safe operation of multiple lights and provides an easy way to manage the relatively high current switching needs of multiple light installations.
FEATURES
- Individual fuse for each light
- Color-coded quick connect terminals for intuitive installation
- Recommended when installing 3 or more underwater lights
SPECIFICATIONS
- Compatible with 12 or 24V systems
- Up to 10 amps per channel
- Up 4 AWG input power lugs
- IP67 wash down rated enclosure
